Seat Adjustment for 2012 Mercedes-Benz GLK350
No.
Part # / Description / Price
Price
10
10
30
Parts Kit, Electric Motor
Mercedes-Benz
Mercedes-Benz Description: Inclination adjustment, left seat. Angle adjustment, left.
$450.00
$450.00
30
Parts Kit, Electric Motor Mercedes-Benz
Mercedes-Benz Description: Inclination adjustment, right seat. Angle adjustment, right.
$370.00
$370.00
30
$690.00
30
$595.00
50
Height Adjustment Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Right seat.
$2,240.00
$2,240.00
60
Holder Mercedes-Benz
Mercedes-Benz Description: Line holder. Multiway connector. Connector block, left and right seats. Left seat adjustment.
$15.00
$15.00
70
Parts Kit, Mounting Rail Mercedes-Benz
Mercedes-Benz Description: Front. Parts set, left. (parts kit), left.
$34.50
$34.50
80
$9.00
85
Parts Kit, Electric Motor Mercedes-Benz
Mercedes-Benz Description: Inclination adjustment, left seat. Angle adjustment, left.
85
Parts Kit, Electric Motor Mercedes-Benz
Mercedes-Benz Description: Inclination adjustment, right seat. Angle adjustment, right.
90
Parts Kit, Electric Motor Mercedes-Benz
Mercedes-Benz Description: Height adjustment, left seat. Height adjustment, left, for, memory.
$665.00
$665.00
90
Parts Kit, Electric Motor Mercedes-Benz
Mercedes-Benz Description: Height adjustment, right seat. Height adjustment, right, for, memory.
100
$70.00
100
$63.00
120
Switch Block Mercedes-Benz
Mercedes-Benz Description: Lordotic support, right side. Left seat. Seat adjustment, right.
130
Shell Mercedes-Benz
Mercedes-Benz Description: Left seat adjustment. At front seat adjustment. At seat box. Seat adjuster.
$4.70
$4.70
140
Mounting Bracket Mercedes-Benz
Mercedes-Benz Description: At front seat adjustment. Left seat adjustment. Cushion shelf to seat adjustment. Seat adjuster. Mounting, shell.
$4.50
$4.50
150
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Cushion shelf to seat adjustment. M6X12
Diameter: 6mm
Strength / hardness class: 8.8
Thread pitch: 1mm. Seat adjustment at cushion frame. On bow,left. Cushion frame to seat frame. Cushion to seat adjustment, left. Clip fastening.
Diameter: 6mm
Strength / hardness class: 8.8
Thread pitch: 1mm. Seat adjustment at cushion frame. On bow,left. Cushion frame to seat frame. Cushion to seat adjustment, left. Clip fastening.
$2.40
$2.40
210
End Stop Mercedes-Benz
Mercedes-Benz Description: For forward seat adjustment, left rail. Electric seat adjustment. For seat adjustment towards front, right rail. Seat adjuster.
250
Self-Tapping Screw Mercedes-Benz
Mercedes-Benz Description: M10X28
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Fastening reinforcement. Seat mounting. Front seat to cross member. At console. Console to floor. Front seat to console m8x28. Seat framework to floor. Left. Reinforcement to tunnel at front.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Fastening reinforcement. Seat mounting. Front seat to cross member. At console. Console to floor. Front seat to console m8x28. Seat framework to floor. Left. Reinforcement to tunnel at front.
$28.75
$28.75
280
Plug Mercedes-Benz
Mercedes-Benz Description: Seat separation point connector carrier. Cover, separation point, seat. Left.
$11.00
$11.00
300
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat n32/1.
$536.00
$536.00
300
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat n32/1. Right seat n32/2.
$372.00
$372.00
904
Plug Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. 4-PIN JPT, MT3. Motor side flap rear shelf 4-pin m49/1. 4-pin jpt, mt3. Belt feeder,left a 10. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1. M28/1. 4-pin jpt, mt3. Seat height adjustment,rear m27/2, m28/2. 4-pin jpt, mt3. Driver fore/aft seat adjustment motor m27/1. 4-pin jpt, mt3. Seat adjuster plug-connection x54. 4-pin jpt, mt3.
$6.50
$6.50
904
Lock Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. Driver seat adjustment.
$3.00
$3.00
914
Plug Mercedes-Benz
Mercedes-Benz Description: Driver partially electric seat adjustment switch s22/1*1. 12-pin slk2.8model 1: slkmodel 2: 2.8slots: 12release tool: w220 589 01 99 62. M1. 12-PIN SLK2.8Model 1: SLKModel 2: 2.8Slots: 12Release tool: W220 589 01 99 62. Switch for seat adjustment,left s22. ...
$8.75
$8.75
914
Receptacle Mercedes-Benz
Mercedes-Benz Description: S22/1. Driver seat partially electric seat adjustment switch. Connector: 1. 2-pin slk2.8. Rear-end door control module m111/e. 2-pin slk2.8.
914
Receptacle Mercedes-Benz
Mercedes-Benz Description: S22/1. Driver seat partially electric seat adjustment switch. Connector: 3. 2-pin slk2.8.
914
Receptacle Mercedes-Benz
Mercedes-Benz Description: S22/1. Driver seat partially electric seat adjustment switch. Connector: 2. 2-pin slk2.8.
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
