Instrument Panel and Gloves Compartment Box with Passenger Air Bag for 2011 Mercedes-Benz SLK300
No.
Part # / Description / Price
Price
110
Tapping Screw
Mercedes-Benz
Mercedes-Benz Description: B4,8x22. Lighting unit to lateral stiffening. Water tank to bracket.
$1.70
$1.70
120
Spring Nut Mercedes-Benz
Mercedes-Benz Description: Foglamp bracket to bumper bracket. Screening on frame-type integral support.
$22.00
$22.00
170
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: At bracket. M5x12. At console. At radiator. Fastening for lining. Fastening of cable bracket. Mounting, tank.
$1.70
$1.70
180
200
Adhesive Label Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Automatic child seat recognition. Notice for child restraint system.
200
Adhesive Label Mercedes-Benz
Mercedes-Benz Description: Note on front passenger airbag on insttrument panel. Notice for child restraint system. Co-driver's air bag. Automatic child seat recognition. Note for child restraint system. Front passenger side. Airbag, passenger side. Instrument panel. Co-driver's side klebeschild.
$6.25
$6.25
280
Interior Lamp Mercedes-Benz
Mercedes-Benz Description: Pigeonhole. In central console. Glove compartment lighting. Stowage compartment center console. Storage tray.
$37.50
$37.50
285
Bulb Mercedes-Benz
Mercedes-Benz Description: For license plate. 12V-5WModel 1: C5WVolt: 12VWatt: 5W. Glove compartment lamp r 5w - 12v. 12v-5wmodel 1: c5wvolt: 12vwatt: 5w. Tail and clearance lights r5w-12v. 12v-5wmodel 1: c5wvolt: 12vwatt: 5w. Courtesy lamp r5w-12v. 12v-5wmodel 1: c5wvolt: 12vwatt: ...
$28.00
$28.00
300
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Instrument panel upper part to steering column jacket tube mounting plate 4.8 x 22. 4.8x16. Covering below instrument panel,left. 4.8x16. 4,8x22. 4.8x16. Instrument panel,bottom,driver's side. 4.8x16. Foot operated parking brake release handle to instrument panel 4.8 x 22. 4.8x16.
$37.50
$37.50
330
900
Plug Mercedes-Benz
Mercedes-Benz Description: On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...
$8.00
$8.00
910
Electric Line Mercedes-Benz
Mercedes-Benz Description: Passenger airbag, ignition squib 1 r12/4. Driver seat belt force limiter R12/27. Front passenger airbag, green r12/5. Front passenger airbag, yellow. Squib 1 airbag passenger side r12/4. Left windowbag r12/22.
$59.00
$59.00
910
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ALSO ORDER: TERMINAL BLOCK 2 X A 001 546 99 41; CABLE TIE 5 X A 002 997 24 90
Description: Squib 1 airbag passenger side r12/4. 2-pin 0.5mm2. Passenger airbag, ignition squib 1 r12/4. 2-pin 0.5mm2. Primer pellet code b / 90�. 2-pin 0.5mm2.
$51.00
$51.00
910
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ALSO ORDER: TERMINAL BLOCK 2 X A 001 546 99 41; CABLE TIE 5 X A 002 997 24 90
Description: Squib 2 airbag passenger side r12/5. 2-pin 0.5mm2. Airbag, stage 2 r12/5. 2-pin 0.5mm2. Left rear emergency tensioning retractor squib r12/6. 2-pin 0.5mm2. Front left belt tens. R12/1. 2-pin 0.5mm2. Passenger airbag, ignition squib 2 r12/5. 2-pin 0.5mm2. Primer pellet code a / 90�. 2-pin 0.5mm2. Window airbag left front r12/22. 2-pin 0.5mm2.
$40.00
$40.00
910
Electric Line Mercedes-Benz
Mercedes-Benz Description: Emergency tensioning retractors front and rear. Front passenger airbag, green. Front left belt tens. R12/1. Rear left belt tensioner r12/6. Squib 2 airbag passenger side r12/5. Passenger airbag, ignition squib 2 r12/5.
$63.00
$63.00
2 This part contains hazardous materials. Extra shipping costs apply.
