Rear Axle Mount for 2011 Mercedes-Benz ML450

10

Wheel Carrier

164-350-13-08

Mercedes-Benz

Description: Left.

View Details

10

Wheel Carrier

164-350-14-08

Mercedes-Benz

Description: Right.

$1,770.00

20

Repair Kit, Support Joint

164-352-03-27

Mercedes-Benz

Description: Repair kit. Supporting joint lh.

$404.00

30

5426 - Rear Axle: Nut for Mercedes-Benz Image

Nut

000000-005426

Mercedes-Benz

Description: Suspension strut to spring linkDiameter: 16mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 34,5mmWidth across flats: 24mm. SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 16mmStrength / hardness class: 10Thread code le ...

$22.50

Sold in Pack of 5

$22.50

Sold in Pack of 5

40

Angular-Contact Ball Brg

164-981-04-06

Mercedes-Benz

Notes: OBSERVE WIS
ALSO USE WHEEL HUB

Description: Rear wheel bearing. Front wheel bearing 90mm.

$105.00

50

Retaining Ring

000472-090000

Mercedes-Benz

Description: Wheel bearing to left steering knuckle. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm. WHEEL BEARING TO WHEEL CARRIER LEFT. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm.

$8.75

60

Wheel Hub

164-356-02-01

Mercedes-Benz

Description: Front. Rear.

$185.00

70

Pin

164-427-00-74

Mercedes-Benz

Description: Stop.

View Details

80

Hex Nut W Flange + Piece

001-990-91-54

Mercedes-Benz

Description: Drive shaft to front wheel hub. M24x1.5. Rear axle shaft.

$19.50

100

Transverse Control Arm

164-350-19-06

Mercedes-Benz

Description: Bottom left.

$790.00

100

Transverse Control Arm

164-350-20-06

Mercedes-Benz

Description: Bottom right.

$690.00

110

Rubber Bushing

164-352-01-65

Mercedes-Benz

Notes: IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS

Description: Left control arm. Lower control arm. Transverse control arm.

View Details

120

Bearing Element, Elastom

166-326-02-81

Mercedes-Benz

Description: Left control arm. Rear shock absorbers. Transverse control arm.

View Details

160

Hexagon Head Bolt

910105014018

Mercedes-Benz

Description: M14X1,5X100-10.9
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.

$12.50

160

Hexagon Head Bolt

000000-002353-64

Mercedes-Benz

Description: On frame-type int. M14X95
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.

View Details

160

Hexagon Head Bolt

000000-004028

Mercedes-Benz

Notes: THE OLD PART MUST NO LONGER BE INSTALLED

Description: RIGHT CONTROL ARM
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,FRONT
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.

View Details

160

Hexagon Head Bolt

000000-004020

Mercedes-Benz

Notes: THE OLD PART MUST NO LONGER BE INSTALLED

Description: LEFT CONTROL ARM. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,REAR. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSVERSE CONTROL ARM AT BOTTOM TO INTEGRAL CARRIER. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.

View Details

180

3277 - Rear Axle: Nut for Mercedes-Benz Image

Nut

000000-003277

Mercedes-Benz

$40.00

Sold in Pack of 10

$40.00

Sold in Pack of 10

180

5307 - Rear Axle: Nut for Mercedes-Benz Image

Nut

000000-005307

Mercedes-Benz

Notes: THE OLD PART MUST NO LONGER BE INSTALLED

Description: Hydropneumatic spring leg to spring control arm. M14X1.5-10
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 21mm. Control arm to support. To left transverse control arm. Control arm to frame,front. Lower control arm. Suspension strut to supporting joint.

$7.00

200

Handle Bar

164-350-14-06

Mercedes-Benz

Description: Strut. Top front.

$175.00

210

Hexagon Head Bolt

000000-003840-64

Mercedes-Benz

Description: Strut rod to wheel carrier, left and right. M12X1,5X85
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.

View Details

210

Hexagon Head Bolt

000000-004033

Mercedes-Benz

Notes: NO LONGER AVAILABLE
THE OLD PART MUST NO LONGER BE INSTALLED

Description: STRUT TO WHEEL BEARING
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.

$17.50

220

Window

140-357-09-75

Mercedes-Benz

Description: Strut rod to left wheel carrier. Camber struts to wheel bearing. Strut rod to wheel carrier, lh.

$8.00

230

Hexagon Head Bolt

000000-004029

Mercedes-Benz

Notes: THE OLD PART MUST NO LONGER BE INSTALLED

Description: STRUT TO REAR SUBFRAME
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.

View Details

230

Hexagon Head Bolt

910105012011

Mercedes-Benz

Description: Torque strut to frame-type integral support, left and right. M12X1,5X60
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.

$6.00

240

327664 - Rear Axle: Nut for Mercedes-Benz Image

Nut

000000-003276-64

Mercedes-Benz

View Details

240

5306 - Rear Axle: Nut for Mercedes-Benz Image

Nut

000000-005306

Mercedes-Benz

Notes: THE OLD PART MUST NO LONGER BE INSTALLED

Description: M12X1.5-10
Diameter: 12mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 26mm
Width across flats: 18mm. Strut to rear subframe. Torsion bar to rear axle. Rod to shock absorber strut.

$7.75

300

Handle Bar

164-350-16-06

Mercedes-Benz

Description: Camber strut,right. Rear right.

$175.00

300

Handle Bar

164-350-13-06

Mercedes-Benz

Description: Camber strut,left. Rear left.

$184.00

320

Hexagon Head Bolt

000000-003864

Mercedes-Benz

Description: Upper left transverse control arm to body. M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.

$14.00

320

Hexagon Head Bolt

000000-004030

Mercedes-Benz

Description: CAMBER STRUTS TO WHEEL CARRIER
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSMISSION TO SUBFRAME M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.

View Details

360

Eccentric

000-352-01-76

Mercedes-Benz

Description: Camber struts to rear subframe.

$6.00

360

Window

000-352-00-76

Mercedes-Benz

Description: Tie rod to rear axle carrierDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. CAMBER STRUTS TO REAR SUBFRAMEDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. TIE ROD TO REAR SUBFRAMEDi ...

$0.30
