Frame Floor Unit Main Cable Harness for 2007 Mercedes-Benz SLK280
No.
Part # / Description / Price
Price
10
10
10
10
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system - radio preinstallation.
10
10
10
10
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system - radio preinstallation.
10
10
10
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system - radio preinstallation.
10
10
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Level sensor for bi-xenon rear axle.
10
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system - radio preinstallation.
10
10
10
10
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system. Inboard.
10
10
10
10
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Frame floor system - interior.
10
10
10
90
$4.50
400
Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Sealing, separation point in luggage compartment.
900
Plug Mercedes-Benz
Mercedes-Benz Description: Interior socket x58/1. 3-pin wdf2model 1: wdf2slots: 3. Glove box socket x58/31. 3-pin wdf2model 1: wdf2slots: 3. Center console socket x58/40. 3-pin wdf2model 1: wdf2slots: 3. Socket, center console, rear x58/41. 3-pin wdf2model 1: wdf2slots: 3. Load comp ...
$4.20
$4.20
901
Electric Line Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. GLOVE COMPARTMENT LIGHTING E13/1. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. CIGAR LIGHTER R3. 1.5 MM2 WDF2Le ...
$15.00
$15.00
901
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
$28.00
$28.00
901
Plug Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
$4.00
$4.00
902
Distributor Mercedes-Benz
Mercedes-Benz Description: Wake-up signal connector x30/8. Connector distributor,wake-up signal x30/14. In legroom,front left kl.15 (wakeupsignal).
904
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: To a 000 545 95 03. To a 001 545 51 40. T0 a 001 545 52 40. To a 001 545 520 40. To a 001 545 28 81. To 001 545 52 40.
$7.75
$7.75
904
Housing Mercedes-Benz
Mercedes-Benz Description: Driver seat connector block, natural color x55/3*7. 4-pin mlk1.2. Connector block, left and right seats x55/3-x55/4 code b. 4-pin mlk1.2. Multi-point plug driver side x55/3. 4-pin mlk1.2.
$3.40
$3.40
904
Housing Mercedes-Benz
Mercedes-Benz Description: Separation point to left seat x157/26. 2-pin. Connector block, left and right seats x55/3-x55/4. 2-pin. Multi-point plug driver side x55/3. 2-pin.
$11.50
$11.50
904
Plug Mercedes-Benz
Mercedes-Benz Description: Connector block driver seat x55/3. 4-pin mlk1.2. Connector block, left and right seats x55/3-x55/4 code a. 4-pin mlk1.2.
905
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
$11.50
$11.50
907
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$7.00
$7.00
907
Contact Socket Mercedes-Benz
Mercedes-Benz Description: Gold-plated with gel N80. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. GOLD AND YELLOW PIN 5, 7, 9, 11. 0.5-0.75 MM2 MQSLeitungsquerschnit ...
$4.00
$4.00
908
Contact Carrier Mercedes-Benz
Mercedes-Benz Description: Connector, left rear axle electrical distributor, violet x62/32*4. 4-pin mqs. Connector, rear axle distributor, violet x62/32,x62/33,cod.d. 4-pin mqs. Rear axle separation point x62/8 code d. 4-pin mqs.
$4.70
$4.70
908
Contact Carrier Mercedes-Benz
Mercedes-Benz Description: Rear axle distributor connector left x62/8*c. 4-pin mqs. Connector, rear axle distributor, blue x62/32,x62/33. 4-pin mqs. Connector, left rear axle electrical distributor, blue x62/32*3. 4-pin mqs. Connector, right rear axle electrical distributor, blue x62/33. 4-pin mqs. Rear axle separation point x62/8 code c. 4-pin mqs.
$4.20
$4.20
908
Contact Support Mercedes-Benz
Mercedes-Benz Description: Connector, rear axle distributor, black x62/8. 4-pin mqs. Rear axle transfer case plugconnection x62/33. 4-pin mqs. Connector, left rear axle electrical distributor, black x62/32*1. 4-pin mqs. Rear axle distributor x62/33. 4-pin mqs. Rear axle separation point x62/8 code a. 4-pin mqs.
$4.70
$4.70
908
Housing Mercedes-Benz
Mercedes-Benz Description: Rear axle transfer case plugconnection x62/32. Rear axle distributor. 4x4-pin. Rear axle transfer case plugconnection x62/8. 4x4-pin. Rear axle,left and right x62/32, x62/33. 4x4-pin. Rear axle separation point x62/8. 4x4-pin.
$11.50
$11.50
912
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
$4.00
$4.00
915
$7.00
915
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Connector for transceiver part x39/5. 10-pin. Connector cockpit/frame floor system x18/35. 10-pin. Air conditioner cable harness plugconnection. 10-pin. Transceiver connector, black x39/5. 10-pin. Breakdown/information button conn. X39/48. 10-pin. Tail lamp cable harness plugconnection. 10-pin.
916
Housing Mercedes-Benz
Mercedes-Benz Description: Transceiver connector, blue x39/5. 10-pin mqs. Telephone-portable ctel separation point, blue x39/37*3. 10-pin mqs. Breakdown/information button conn. X39/48. 10-pin mqs. Blue center console connector x29/6. 10-pin mqs. Plug connection handy x39/39. 10-pin mqs. Mobile phone disconnecting point. 10-pin mqs. Connector, telephone, armrest, blue x39/47. 10-pin mqs.
921
Plug Mercedes-Benz
Mercedes-Benz Description: Cockpit/frame floor assembly connecting point x18. 5-pin
model 1: mqs
slots: 5. Intermediate connector, airbag x28/12. 5-pin
model 1: mqs
slots: 5.
model 1: mqs
slots: 5. Intermediate connector, airbag x28/12. 5-pin
model 1: mqs
slots: 5.
$3.70
$3.70
922
Plug Mercedes-Benz
Mercedes-Benz Description: Connector cockpit/frame floor system x18. Connector cockpit/frame floor system x 18. Engine compartment connector x25, code a.
924
Plug Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Overhead control panel/ffs connector x25/8. Engine compartment connector x25, code b.
926
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Airbag/driver seat separation point x28/29. 14-pin mqs. Left and right front seats x28/29, x28/30. 14-pin mqs. Contact strip, seat, left and right x55/4. 14-pin mqs. Contact strip front pass. Side yel. X55/3. 14-pin mqs. Airbag separation point, front seat x28/29, x28/30. 14-pin mqs.
$12.50
$12.50
927
Contact Socket Mercedes-Benz
Mercedes-Benz Description: DOOR SEPARATION POINT, REAR X35/3,X35/4. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Copper. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: ...
$7.00
$7.00
