Line Arrangement in Case of Self-Levelling Device, a S D & 4MATIC® for 1989 Mercedes-Benz 300TE
No.
Part # / Description / Price
Price
11
Clamp
Mercedes-Benz
Mercedes-Benz Description: FROM STEERING GEAR ON COOLING LINEInside diameter: 17mmMaterial thickness: 0,6mmWidth across flats: SW7Model 1: W1. CONNECTORInside diameter: 17mmMaterial thickness: 0,6mmWidth across flats: SW7Model 1: W1. FROM OIL PUMP TO HEIGHT CONTROL VALVEInside diame ...
$5.25
$5.25
30
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Description: From expansion tank to additional tank. Right. For molded hose. Line to rear floor center. Fastening, cable, rear center. High pressure expansion hose & connecting hose to side member. Oelverbindungsschlauch durch traeger oelvorratsbehaelter.
$4.40
$4.40
36
$115.00
37
Pressure Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: From control valve to ring cylinder.
41
Hydraulic Line Mercedes-Benz
Mercedes-Benz Description: Connection "t", from control valve to oil reservoir. (return line),connection "t", from control valve to t-fitting.
50
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: (return line) from coupling piece to oil reservoir. Connection "t", from control valve to coupling piece.
60
$107.00
62
Oil Line Mercedes-Benz
Mercedes-Benz Description: (return line) from coupling piece to oil reservoir. From high pressure expansion hose to height control valve. From control valve to self-levelling unit. From high pressure expansion hose to coupling piece.
71
$85.00
82
Line Mercedes-Benz
Mercedes-Benz Notes: USED WITHOUT AUTOMATIC LOCKING DIFFERENTIAL (A S D)
Description: (return line) from self-levelling unit to oil tank.
83
$122.00
86
Connection Piece Mercedes-Benz
Mercedes-Benz Description: M12. To separation point. Line connection. Lines. Pressure line. From high pressure expansion hose to distributor valve.
88
Line Mercedes-Benz
Mercedes-Benz Description: (return line) from coupling piece to oil reservoir. From high pressure expansion hose to coupling piece. From high pressure expansion hose to control valve. From pump to service valve. (return line) from distributor to distributor. From master cylinder,connection "h",to hydraulic unit,connection: "h",teves. High-pressure line to connection fitting. From distributor to oil tank.
$63.00
$63.00
146
149
Hollow Screw Mercedes-Benz
Mercedes-Benz Description: Connecting hose to spring load accumulator,left m 16x1,5. Line to spring-type actuator.
$17.00
$17.00
152
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: CONNECTING HOSE TO HYDROPNEUMATIC SPRING LEG. 16X22
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm. CONNECTING HOSE TO SPRING LOAD ACCUMULATOR,LEFT. 16X22
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm. LINE TO SPRING-TYPE ACTUATOR. 16X22
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm.
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm. CONNECTING HOSE TO SPRING LOAD ACCUMULATOR,LEFT. 16X22
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm. LINE TO SPRING-TYPE ACTUATOR. 16X22
Strength / hardness class: CU
Inside diameter: 16mm
Outside diameter: 22mm
Material thickness: 1,5mm.
$2.70
$2.70
